A brief introduction to the OSI model

The goal of this story is to give a brief introduction into the OSI Model and a helpful way to remember the different layers. Not everything translates nicely into a story format.

Disclaimer: Some of the concepts are simplified. If you have any suggestions or issues, feel free to drop a comment below.

Once upon a time. In a lan far far away. A young boy was walking along a dusty path with his teacher, the old wise wizard of ARPANET. So Arthur, for that was the name of our young boy, how is your learning of the OSI model coming? Truth be told master, I am having the hardest time keeping things straight, and even understanding what a Network Model is. Why are there so many layers and remembering if the presentation comes before the transport, or transport before presentation. It is all very confusing. The old wizard nodded, ah yes, it can be a bit of a muddle and the OSI model is not even the primary model used, but alas, it is a relic that is still taught and expected of students in your order. Fortunately, we have just stumbled upon a great example that may help. They had just arrived at a building that was in the middle of nowhere, but appeared to be heavily guarded. Arthur had not been here before and was not sure what to make of it. The wizard continued, this is one of the kings mines and it looks like they are just about to send off some gold over the Internet.

Sit here on this rock and let’s review what the OSI model is. The OSI Model stands for Open Systems Interconnection is a network model developed by the ISO or International Organization of Standardization. The model is a theoretical model of how a network can send and receive data. Technically, applications can be built on top of this model. However this model has been largely abandoned in favor of TCP/IP. There are some similarities and the OSI model is still taught and referenced, but TCP/IP is simpler and is what people preferred. For instance when someone says “that is a layer 7 problem”, they are referring to the Application layer. But now let us get into the layers. Look, they are loading up the gold.

You see the road there that runs in front of the mine? We can compare the road to the first layer of the OSI model, the Physical Layer. The physical layer is well, the physical medium that is used. There are multiple mediums that could be used. Roads are one, rivers another, we can even use the air wirelessly. There are also more esoteric paths like Fiber and Cable.

The next layer is our cart. This is commonly referred to as layer 2 and has everything to do with switching and MAC addresses.

A cart is useless without a driver, and that is the next layer. Our driver and the routing to the treasury is our Network Layer, layer 3. He follows the IP routes from here to there. The signs help route between road networks so he can get to the destination.

You see the boxes that are being loaded? That is Layer 4. The Transport Layer. We typically have two types of transport TCP and UDP. TCP is in closed boxes that keep the contents from bouncing out while going down the road, there are also mechanisms in place to verify that everything gets to the destination and if something is missing, it will make sure to go back and get it. UDP is a simpler protocol. See that cart over there under the apple tree? They just throw all the apples in and hope it all makes it to the destination. There is no verification that it makes it to the destination, they just send it and hope for the best or handle the errors at a higher layer. It is a simpler protocol and faster. And honestly, if a load of apples goes missing, it is not the end of the world.

Now on the journey, the driver is going to need to be let through the gates into the treasury. We can thinks of the guards and gates as our Session Layer or Layer 5. They initiate the session and will tear it down, close the gates, once the load is delivered.

The presentation layer is next, and it is responsible for converting data from one format to another. Things like formatting, encryption and compression are all executed in this layer. For instance, if the load was a bunch of feathers, it could be compressed down to fit a higher quantity of feathers in the same size cart. In this case, the presentation layer is responsible for encrypting, or locking the box. When it gets to its destination, it will be unlocked so it can be accessed.

Finally, Layer 7. The Application Layer can be thought of as the end user interface. In this case the actual gold coins. We can handle it, look at it, and count them.

That is the OSI layer in a nutshell. It is important to remember that it is only a theoretical framework and not exactly how everything works. There are some protocols that have been built on the OSI model, but most of the Internet uses the TCP/IP model.

Arthur sighed, that is a lot to take in, but having the visual will be helpful. Is there a mnemonic or jingle to help remember the names? Aye, we’ve a few, the old wizard replied smiling. One that has been around for ages is, All People Seem To Need Data Processing. Or you can start at the physical layer and go up with, Please Do Not Throw Sausage Pizza Away. Arthur laughed, why would someone throw sausage pizza away? They both chuckled. Hopefully no one does that Wizard said. Now up, let’s see if we can catch the cart so we can continue our learning.

How to Migrate Email without IMAP credentials

Here are a few ways you can migrate emails without knowing the IMAP credentials.

  1. Use the Admin Password.
  2. Migrate emails using SFTP.
  3. Import/Export using RoundCube?

Use the Admin Password

Some email services allow you to use the administrator password to sign into any email account. This allows you to move emails without knowing the users password.

You can refer to this FAQ on the imapsync website.

https://imapsync.lamiral.info/FAQ.d/FAQ.Admin_Authentication.txt

Migrating Files using SFTP

Disclaimer:

This option will only work if you have ftp/ssh/filesystem access.
Depending on email volume, you could miss emails that arrive during the transition.
If possible, it is recommended to use something like imapsync.
There could be format issues if the two email servers use different mailbox formats and/or email server software.

Emails are usually stored in the users home directory. Depending on the hosting provider, it could be /mail or ~/mail

You can zip up the mail directory and then unzip on the target server. This would only work if you have access to the filesystem. Create your email accounts before unzipping.

You could transfer the passwd and shadow files to keep the email passwords the same. Again, create the email addresses on the target server first and then either overwrite, or merge the differences between the shadow and passwd files.

For example, on cPanel servers, the mail directory is in ~/mail and the shadow and passwd files are in ~/etc/DOMAIN.COM

If you are logged in as root, you will need to change ~/ to /home/USER/ substituting USER for the actual cPanel user.

Import/Export messages from RoundCube?

You can import and export emails using the RoundCube webmail interface. However, the export is limited to one. message. at. a. time. This could work for a handful of messages, but can get quite tedious if you have a large number of emails.

How to enable Ping Watchdog on Ubiquiti AirOS from Command Line

Ping Watchdog is a feature that will automatically reboot a device if the specified IP address is unreachable.

Here is a quick run down on enabling Ping Watchdog on Ubiquiti Radios from the command line.

1. SSH into the radio

ssh ubnt@192.168.1.20

2. Edit the config file

vi /tmp/system.cfg

Find the lines that start with pwdog

At a minimum, you will need to change the following two options:

  • pwdog.status to enabled
  • pwdog.host to the IP you want to ping. Add this line if it does not exist.
pwdog.delay=300
pwdog.host=192.168.1.1
pwdog.period=300
pwdog.retry=3
pwdog.status=enabled

You can adjust the other options to your desired taste.

Exit vi by hitting esc then typing in wq then hit Enter

3. Save configuration

Finally, save the configuration changes with

/usr/etc/rc.d/rc.softrestart save

How to Set up a PowerDNS Recursor

The following are the steps needed to install a PowerDNS recursor on RHEL, Fedora, Rocky Linux, or AlmaLinux

Install from package manager with

yum install pdns-recursor

Allow DNS through Firewall

sudo firewall-cmd --add-service=dns --permanent

Configure the `/etc/pdns-recursor/recursor.conf` file. The local-address is the DNS recursor, the allow-from, are the addresses you would like to allow access to

local-address=192.0.1.2
allow-from=192.0.0.0/16, 10.0.0.0/8

Start and enable the `pdns-recursor` service

systemctl enable --now pdns-recursor

https://doc.powerdns.com/recursor/getting-started.html

Ansible not working on RockyLinux 8, AlmaLinux 8, RHEL 8

[WARNING]: Unhandled error in Python interpreter discovery for host localhost: Expecting value: line 1
column 1 (char 0)

https://github.com/ansible/ansible/issues/83357

Ansible 2.17 moved to using Python 3.7. This causes issues with systems that use Python 3.6 (i.e., RHEL 8 based distros). Unfortunately, you can’t just upgrade Python either, as 3.6 is used in system tools such as DNF/YUM.

There are two options.

  1. Upgrade to a RHEL 9 based distribution
  2. Use Ansible 2.16

Ansible 2.16 should be the default installed version on RHEL 8 based distros.

Migrate CentOS 7 to AlmaLinux 8

The steps are taken from this page https://wiki.almalinux.org/elevate/ELevating-CentOS7-to-AlmaLinux-9.html

To upgrade to AlmaLinux 9, you will need to migrate to AlmaLinux 8 first.

sudo curl -o /etc/yum.repos.d/CentOS-Base.repo https://el7.repo.almalinux.org/centos/CentOS-Base.repo
sudo yum upgrade -y

Once yum finishes, reboot

sudo reboot

Now install elevate-release and leapp packages

sudo yum install -y http://repo.almalinux.org/elevate/elevate-release-latest-el$(rpm --eval %rhel).noarch.rpm
sudo yum install -y leapp-upgrade leapp-data-almalinux

Let’s run a pre upgrade check to see if there are any errors.

sudo leapp preupgrade

If everything checked out ok, proceed with the upgrade.

sudo leapp upgrade

Once finished, reboot.

sudo reboot

Once the system is booted, verify it upgraded.

cat /etc/*release

Problems

https://wiki.almalinux.org/elevate/ELevate-frequent-issues

LUKS

If you are using LUKS and encounter an error, check out the following link.

https://www.it-hure.de/2024/02/update-alma-rhel-with-leapp-and-luks/

You can disable the check with the following command.

rm -rf /usr/share/leapp-repository/repositories/system_upgrade/common/actors/inhibitwhenluks

More space needed on / filesystem

Try setting LEAPP_OVL_SIZE to 4096

export LEAPP_OVL_SIZE=4096

Then launch the upgrade with

sudo --preserve-env leapp upgrade

https://forums.almalinux.org/t/at-least-48mb-more-space-needed-on-the-filesystem-running-leapp-upgrade/3808/2

You can also try removing files to create more free space.

https://github.com/oamg/leapp/issues/778

Upgrading to 8.8 (Or 8.4)

For the same reason, we recommend upgrading your CentOS 7 machine to AlmaLinux OS version 8.8. To do so, you need to navigate to the /etc/leapp/files/ directory and edit the leapp_upgrade_repositories.repo to lower the AlmaLinux version in baseurl/mirror to 8.8.

The 8.8 repositories are archived. To upgrade to AlmaLinux 8.8, change ‘/etc/leapp/leapp_upgrade_repositories.repo” to the following.

[almalinux8-BaseOS]
name=AlmaLinux 8 - BaseOS
baseurl=https://vault.almalinux.org/8.8/BaseOS/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

[almalinux8-AppStream]
name=AlmaLinux 8 - AppStream
baseurl=https://vault.almalinux.org/8.8/AppStream/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

[almalinux8-PowerTools]
name=AlmaLinux 8 - PowerTools
baseurl=https://vault.almalinux.org/8.8/PowerTools/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

[almalinux8-HighAvailability]
name=AlmaLinux 8 - HighAvailability
baseurl=https://vault.almalinux.org/8.8/HighAvailability/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

[almalinux8-ResilientStorage]
name=AlmaLinux 8 - ResilientStorage
baseurl=https://vault.almalinux.org/8.8/ResilientStorage/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

[almalinux8-Extras]
name=AlmaLinux 8 - Extras
baseurl=https://vault.almalinux.org/8.8/extras/$basearch/os/
enabled=1
gpgcheck=1
gpgkey=file:///etc/pki/rpm-gpg/RPM-GPG-KEY-AlmaLinux

If you have issues, you may consider upgrading to 8.4 first. To do that, change 8.8 to 8.4, and comment out the ResilientStorage section.

GPG Key failing after upgrade

Try importing the AlmaLinux 8 GPG key

rpm --import https://repo.almalinux.org/almalinux/RPM-GPG-KEY-AlmaLinux

https://almalinux.org/blog/2023-12-20-almalinux-8-key-update

Differences between RTO, RPO, MTBF, and MTFF

Here is a quick overview of the differences between, RTO, RPO, MTBF, and MTFF.

NameMeaning
RTO (Recovery Time Objective)Time it takes to recover from a disruption, system failure, data loss etc.
RPO (Recovery Point Objective)How much data can you afford to loose? If RPO is 24 hours, then backups need to be performed daily.
MTBF (Mean Time Between Failures)Time between failures. Use for repairable systems
MTTF (Mean Time to Failure)Time before system fails. Use for nor repairable systems.

http://techtarget.com/whatis/definition/recovery-point-objective-RPO

http://rubrik.com/insights/rto-rpo-whats-the-difference

http://en.m.wikipedia.org/wiki/Mean_time_between_failures

Securely Delete Files on Linux

We can use srm to securely delete files on Linux.

Install srm with

sudo apt install secure-delete

We can now securely delete files by running

srm filetodelete.txt

# srm --help
srm v3.1 (c) 1997-2003 by van Hauser / THC <vh@thc.org>

Syntax: srm [-dflrvz] file1 file2 etc.

Options:
-d ignore the two dot special files "." and "..".
-f fast (and insecure mode): no /dev/urandom, no synchronize mode.
-l lessens the security (use twice for total insecure mode).
-r recursive mode, deletes all subdirectories.
-v is verbose mode.
-z last wipe writes zeros instead of random data.

srm does a secure overwrite/rename/delete of the target file(s).
Default is secure mode (38 writes).
You can find updates at http://www.thc.org

Other links for securely erasing drives.
https://www.tomshardware.com/how-to/secure-erase-ssd-or-hard-drive

Top 8 Nmap options

Here are 8 excellent Nmap options, what they do, and why you would use them.

Most of the options can be run together. You will normally want to perform scans with administrator or root privileges.

OptionWhat is doesWhy you would use
1.-snNo port scanHelpful for quickly discovering hosts that are up
2.-iL file.lstScan IP addresses in file.lstHelpful if you already have a list IP addresses to scan
3. -nSkip reverse DNS lookupThis can help speed up scanning
4.-PnPretend host is upUse when hosts have Ping disabled. e.g. Windows
5. -OOS detectionUse to detect OS version
6.-T4Speed up scanIncreases scan speed (Default is -T3)
7.-AAggressive scan optionsShorthand option. Enables OS detection (-O), version Scanning (-sV), script scanning (-sC), and runs a traceroute
8.-oA filenameSave output to ALL formatsThis saves the output to separate files for XML and grepable formats
Nmap table: 8 common options.

A Quick Overview of SAML

SAML stands for Security Assertion Markup Language. It allows for Single Sign On or SSO to a service.

There are three entities or roles involved when using SAML to sign into a service.

  1. Principal or Subject: a.k.a. you, or the person or service logging in.
  2. Service Provider (SP): This is the service you are accessing. It could be email, a website, etc.
  3. Identity Provider (IdP): This is the entity response for authenticating the Principal.

As an example, let’s say you want to log into a new website utilizing your email SSO credentials. You click the SSO login button, you are redirected to the IdP to login. Once authenticated, your device will receive a token which is then passed back to the Service Provider and allows you access to the new website.

This is a very simplified version of what happens when you login using SAML. It may be helpful to know that the Service Provider and the Identify Provider will have needed to be configured to work together before the user attempts to log in.

https://auth0.com/blog/how-saml-authentication-works

https://infosec.mozilla.org/guidelines/iam/saml.html
